Produktbeschreibung
Alle Modelle verfügen über die neue Hawke H7 Optik mit hohem Zoomfaktor sowie überlegener Klarheit und Lichtdurchlässigkeit.
Precision build components and larger 34mm monotube construction designed for extreme long range shooting.
- Hohe, Arretierbare Zero-Stop Stelltürme
- Absehen In Der Ersten Bildebene (FFP)
- 34mm Mono-Tube Chassis
- Seitenfokus
- Absehenbeleuchtung
- Weitwinkelsichtfeld
- Großer Okulardurchmesser
- 102mm Augenabstand
- Multi-LED Hochsichtbares Absehen
- Hochwertiges, Streuungsarmes Spezialglas
- 21 Lagige Vollständige Mehrschichtvergütung Der Linsen
- Zoomhebel (Abnehmbarer)
- Schnellfokusokular Und Sicherungsring
- Schnellfokusokular Mit Arretierung
-
Stickstoff Gefüllt. Stoßfest. Wasserdicht. Beschlagfrei.
Alle Kaliber
FFP Mil Pro Ext. Absehen (30x)
The FFP Mil Pro Ext. reticle was developed specifically for first focal plane optical systems and based around the common principles of Mil spaced reticles. With Mil spaced markings extending out to 15 Mil of holdover, the FFP Mil Pro Ext is a versatile reticle that provides aim points no matter how extreme the distance.
All reticle measurements are Mil spaced and offer 1 Mil, 0.2 Mil and 0.1 Mil brackets for range finding. Every Mil spacing on the lower section is numbered to ensure quick and easy acquisition of target and ease of reference.
The thick outer posts are hollowed to ensure they can be seen at all magnifications, without blocking out too much of the view.
-
When the magnification is increased, the reticle increases in size along with the image you are looking at.
MIL-MIL SETUP
The Mil spaced reticle and 1⁄10 MRAD turrets make for easy point of aim adjustment. Every 10 clicks on the turret will measure exactly 1 Mil spacing on the reticle, also known as 1 MRAD. Because of FFP this is true on all magnifications.
IMPERIAL
1 MRAD = 1yd @ 1000yds, or 3.6in @ 100yds. At different ranges this MRAD gap will change: 50yds = 1.8in, 100yds = 3.6in, 200yds = 7.2in, 300yds = 10.8in.METRIC
1 MRAD = 1m @ 1000m, or 10cm @ 100m. At different ranges this MRAD gap will change: 50m = 5cm, 100m = 10cm, 200m = 20cm, 300m = 30cm.
Länge:
392mm
15.4"
Gewicht:
830g
29.3oz
Augenabstand:
102mm
4"
Fokus/Parallaxe - Seitenfokus
14m — ∞
15yds — ∞
Sichtfeld:
7.5 — 1.3m @100m
22.5 — 3.8ft @100yds
Austrittspupille:
11.2-1.9mm
0.44-0.07"
Gehäuse
34mm Monorohr
Optiksystem
5-30x
Objektiv
56mm
Beleuchtung
Rot (11 Helligkeitsstufen with Off Positions In-between)
Absehen
Mil Pro Ext
Erhöhungsschritt
1⁄10 MRAD
Höhenanpassungsbereich:
29 MRAD
Windage Increment
1⁄10 MRAD
Windage-Einstellbereich
15 MRAD
Stoff
Aluminium
Okular der Typ
Arretierbare Schnellfokus
Linsenoberflächen
Mehrschichtvergütung - 21 Fach
Leistungsauswahl
Abnehmbaren ZoomHebel
Bildebene
Erste Bildebene (FFP)
Türme Kappe
No
Türme
Ausgesetzt Zero Lock 'n' Stop Turrets (Patented)
